CI-550

Fully automated casing in system

Introducing

CI 550

*All-in-one integrated Fully automatic system

Description

CI-550 is a fully automatic casing in machine. The hard cover and bookblock are fed into machine automatically. The machine detects the thickness of the bookblock, sprays the hotmelt, assembles the cover on the bookblock in centre position. It includes heat and pressure unit, can reactivate the hot melt in the joint to make it more pronounced and precise. It is compact and save the space of operation.

Description

Specifications

machine image

CI 550

Fully automated casing in system which integrates auto feeding, gluing, assembling and a joint forming station.
Speed: 540 Books per hour

  • Min. 150mm / Max. 420mmMin. 150mm / Max. 370mm
  • Min. 8mm / Max. 55mm Min. 4mm / Max. 50mm
  • Up to 9 books /min
  • 1-2 minutes
  • 0.8mpa, >300L/min
  • Hot melt
  • 220V 50HZ Single phase
  • 3000W
  • 3500(L) x 3400(W) x 1800(H) mm
  • 850kg

Details

Key Features

  • Hotmelt gluing technology: cheaper cost and faster delivery;

  • Hotmelt glue to replace double side tape, it saves the cost of material and labor;

  • Easy to operate via touch screen;

  • Flexible production for different sizes and shapes;

  • Easy clean spray platform;

CI-550 is a fully automatic casing in machine. The hard cover and bookblock are fed into machine automatically. The machine detects the thickness of the bookblock, sprays the hotmelt, assembles the cover on the bookblock in centre position. It includes heat and pressure unit, can reactivate the hot melt in the joint to make it more pronounced and precise. It is compact and save the space of operation.
