LayFlat IND330-2000 – Zeno360
The LayFlat IND330-2000
Create stunning lay flat books, fast!The LayFlat IND330-2000 is your all-in-one solution for high-speed, automated book block production.
From single sheets to beautifully finished lay flat books, this system does it all. Produce premium photo books with back-to-back gluing or rigid cardboard inserts.
The perfect partner to a high speed digital press such as HP Indigo, industrial toner, or inkjet devices.
Perfect for: Coffee table books, journals, notebooks, textbooks, corporate publications, product catalogues, and children's books.
Key Features
- All in one system : Integrated auto feeding, gluing, assembling units and online presser.
- High speed : 2000 cycles/hour.
- Industrial grade : can run 24 hours per day, big volume paper and cardboard stacker.
- Fully automatic : with bar code scanning system, don't need operator intervention.
- Layflat binding technology.
- Hotmelt gluing technology : cheaper cost and faster delivery.
Specifications
- Book block height : 203 mm x 330 mm
- Book block width (open) : 355 mm x 750 mm
- Maximum thickness of book block : 50 mm
- Cardboard : With or without
- Glue : Hot melt
- Speed : 2000 cycles/hour
- Power Supply : 220V 50HZ Single phase
- Maximum Power Consumption : 2700 W
- Machine dimension : 2.95 (1) x 1.80 (W) x 1.50 (H) m
- Weight : 1500 kg
- Air Compressor : 0>0.8mpa, 300L/min
- Thickness of cardboard : 0.35 mm-1mm
- Thickness of paper : 0.15 mm-0.3 mm
For More Information
Interested in learning more about the LayFlat IND330-2000 or other products?
For More Information: Contact your local Independent Photographic Supplies Technical Sales Agent – See Contact Map for detail
