LayFlat IND330-600 – Zeno360
The LayFlat IND330-600
Compact, but feature rich!The LayFlat IND330-600 is your compact all-in-one solution for high-speed, automated book block production, for smaller production runs in smaller spaces
From single sheets to beautifully finished lay flat books, this system does it all. Produce premium photo books with back-to-back gluing or rigid cardboard inserts.
Key Features
- All in one system: Integrated auto feeding, gluing, assembling.
- Easy to operate via touch screen.
- Flexible production for different sizes: 6”x6” to 13”x 18”.
- Layflat binding technology.
- Hotmelt gluing technology: cheaper cost and faster delivery.
Specifications
- Book block height : 152 mm x 330 mm
- Book block width (open) : 305 mm x 915 mm
- Maximum thickness of book block : 50 mm
- Cardboard : With or without
- Glue : Hot melt
- Speed : 600 cycles/hour ( without cardboard),
400 sheets /hour ( with cardboard) - Power Supply : 220V 50HZ Single phase
- Maximum Power Consumption : 2000W
- Machine dimension : 2.13 (1) x 0.85 (W) x 1.45 (H) m
- Weight : 400 kg
- Air Compressor : 0.6-0.7mpa, 3180L/min
- Thickness of cardboard : 0.35 mm-1mm
- Thickness of paper : 0.15 mm-0.3 mm
For More Information
Interested in learning more about the LayFlat IND330-600 or other products?
For More Information: Contact your local Independent Photographic Supplies Technical Sales Agent – See Contact Map for detail
